Heimdall is Barco Residential’s first single chip Native 4K projector for exquisite resolution and detail. The RGB laser light engine supports the REC2020 color gamut, ensuring faithful reproduction of every color in every movie.
The brand new RGB laser light engine gives Heimdall its incredible brightness with a long lifetime of 25,000 hours, even at full power. The solid state design has no moving parts for the absolute highest reliability.
HDMI 2.1 is the latest standard for connectivity. It allows frame rates up to 120Hz. This makes it an ideal match for our low latency design and is perfect for advanced gaming applications.
DynaBlack provides frame by frame contrast enhancement which analyzes each frame of video. It then uses ultra-fast processing and laser pulsing to increase the overall dynamic range, making darker scene’s darker and brighter scenes brighter
Pulse is a hardware and software based platform that simplifies the signal path, allowing it to go from source to screen much faster and more efficiently. We use an advanced image processing technique to display the image on the screen without any artifacts and with virtually no latency at speeds up to 120Hz at Native 4K resolution.
Single Step Processing (SSP™) provides geometry correction, warping, blending & more for ultimate installation flexibility.
7 different lenses are available, including the all-new EN83. This allows the Heimdall to be installed in virtually any room and in any location.
Product Specifications
Projector type: 4K 1-chip DLP RGB laser projector
Light source lifetime: 25,000 hours: 100% power/25°C/sea-level
Installation: Free Rotation
Technology: Single Chip 4K DMD, Solid State RGB Laser
Resolution: Native 4K: 4,096 x 2,176 pixels
Aspect ratio: 1.88:1
Light source: Solid State RGB Laser
Light output: 4,500 ANSI lumens
Contrast ratio: 20,000:1 (with DynaBlack)
Input resolutions: Including and up to: 4,096 x 2,160 @ 120Hz RGB/YCbCr 4:4:4 12bit
Lens range:
Note: All throw ratios adjusted for 0.98” DLP device
0.53:1 (EN67)*
0.70-1.06:1 (EN66)*
0.83-1.14:1 (EN76)*
1.06-1.50:1 (EN63)*
1.10-1.61:1 (EN83)
1.48-2.18:1 (EN61)*
2.19-4.05:1 (EN64)*
* Requires York lens adaptor (R9802623) for FLDX/FLD+ lenses
Optical lens shift: Varies depending on lens
Color correction: P7 RealColor™
Color gamut: REC709, DCI-P3, 98% REC2020
Image processing: Embedded warp & blend engine
Network connection: 10/100/1000 Mbit
Operational humidity: 20 - 80% RH
HDR: HDR10, HLG
3D: Active Stereoscopic 3D
Inputs: HDMI 2.1 (HDCP 2.3)
Control: IR, RJ45, Optional Cabled Remote
Storage temperature: -20 to 60 °C
Shipping dimensions (WxLxH): 560 x 765 x 410 mm / 22.1 x 30.1 x 16.1 in. (excluding lens)
Storage humidity: 10 - 90% RH
Power requirements: 7-3A, 100-240V~, 50/60Hz
Certifications: CE, FCC Class A and cCSAus
Power consumption: 520W typical, 750W maximum
Noise level (typical at 25°C/77°F): 30dB (29dB at 20°C/68°F)
Operating temperature: 10 - 40°C (sea level)
Operating humidity: 20 - 80% RH
BTU per hour: 1,774 BTU/h typical, 2,545 BTU/h maximum
Dimensions (WxLxH): 473 x 563 x 293 mm / 18.6 x 22.2 x 11.6 in (excluding lens and feet)
Weight: 31 kg/68 lbs
Warranty: Limited 3 years parts and labor, extendable up to 5 years
Safety requirements: RG2*, *Only lenses specified in the installation manual are permitted for installation.
