The brand new RGB laser light engine gives Heimdall its incredible brightness with a long lifetime of 25,000 hours, even at full power. The solid state design has no moving parts for the absolute highest reliability.
Supporting HDMITM 2.1 and HDCP 2.3 this projector also supports consumer video standards including 4K UHD.
9 different lenses are available, from ultra short throw to extreme long throw. This allows the Heimdall to be installed in virtually any room and in virtually any location.
Heimdall is Barco Residential’s first single chip Native 4K projector for exquisite resolution and detail. The RGB laser light engine provides 98% of the BT2020 color gamut, ensuring faithful reproduction of every color in every movie.
Pulse is a hardware and software based platform that simplifies the signal path, allowing it to go from source to screen much faster and more efficiently. We use an advanced image processing technique to display the image on the screen without any artifacts and with virtually to no latency at speeds up to 240hz at Native 4K resolution.
Single Step Processing (SSP™) provides geometry correction, warping & blending & more for ultimate installation flexibility.
Product Specifications
Resolution Native 4K: 4,096 x 2,176 pixels
Display Technology: Single Chip 4K DMD TM
Housing: Sealed DMDs and Optical Assembly
Input Compatibility: Including & up to 4,096 x 2,160 @ 120hz, RGB/YCbCr 4:4:4 12 bit
Light Output: 6,000 ANSI lumens
Contrast: 20,000:1 (with DynaBlack)
Light Engine: Solid State RGB
Laser Laser: Life 25,000 hours: 100% power/25°C (77°F)/sea-level
Lenses:
Note: All throw ratios adjusted for 0.98” DLP device on Heimdall
0.53:1 (EN67)*
0.70-1.06:1 (EN66)*
0.83-1.14:1 (EN76)*
1.06-1.50:1 (EN63)*
1.10-1.61:1 (EN83)
1.48-2.18:1 (EN61)*
2.19-4.05:1 (EN64)*
* Requires York lens adaptor for FLDX/FLD+ lenses
Lens Shift Range: Varies depending on lens
Inputs: HDMI 2.1 (HDCP 2.3)
Control: IR, RJ45, Optional Cabled Remote
Control Drivers: Control4, Crestron, Josh.ai (US), RTI and Savant
3D: Active Stereoscopic 3D
Dimensions: (WxLxH) 473 x 563 x 293 mm / 18.6 x 22.2 x 11.6 in. (excluding lens & feet)
Shipping Dimensions: (WxLxH) 560 x 765 x 410 mm / 22.1 x 30.1 x 16.1 in. (excluding lens)
Weight: 31 kg/68 lbs
Power Requirements: 7-3A, 110 - 240 V~, 50/60Hz
Power Consumption: 610W typical, 750W maximum
BTU per Hour: 2,081 BTU/h typical, 2,545 BTU/h max
Noise Level: 29dB: 100% power/25°C (77°F)/sea-level
Operating Temperature: 10 - 40°C (sea level)
Operating Humidity: 20 - 80% RH
Installation: Free Rotation
Certifications: CE, FCC Class A and cCSAus Color Gamut REC709, DCI-P3, 98% REC2020 Warranty Limited 3 years parts and labor, extendable up to 5 years
Safety Requirements: RG2, however, this projector may become RG3 when used without lens, or when a lens with a throw ratio greater than or equal to 2.2 is installed.
