Unleashing Pure Power
At its core lies Goldmund’s proprietary Telos® amplification technology, a meticulously engineered Class A/B circuit that merges the linearity of analog components with a high-bandwidth architecture. The result? Unparalleled sonic purity with ultra-low distortion and maximum efficiency.
Mastery in Motion
Telos® amplifiers are designed for absolute speaker control, providing clean power while preserving the integrity of the audio signal. Proper driver control ensures high-fidelity sound reproduction without distortion or unwanted artifacts.
This is particularly key in low frequencies, preventing woofer diaphragms from excessive motion and, hence, unwanted vibrations. By enhancing linearity of each amplification stage, Telos® technology virtually eliminates harmonic and intermodulation distortion. A higher-bandwidth circuit reduces group delay distortion, ensuring impeccable timing and sonic coherence.
Sonic Perfection, Engineered
Goldmund’s advanced circuit architecture separates high and low-current circuits, preventing feedback and interference for pristine audio signal transmission. The integration of Mechanical Grounding technology further enhances signal purity by channeling vibrations directly into the ground.
The sophisticated output impedance reduction improves micro-dynamics, controls excessive woofer overshot in high-power conditions, and eliminates unnaturally “boomy” bass, guaranteeing absolute sonic transparency.
Specification
Amplifier Type: Mono (Monoblock)
Operating Class: Class A/B with Goldmund Telos® technology
Power Output @ 8Ω: 1,050 W RMS (1% THD)
Power Output @ 4Ω: 1,800 W RMS
Power Output @ 2Ω: 2,100 W RMS
Power Output @ 1Ω: 2,200 W RMS (protected)
Damping Factor: 600 @ 1 kHz / 8Ω
THD+N: <0.005% (20 Hz–20 kHz, 30 Vrms)
IMD (SMPTE): <0.01%
Dynamic Range: 117 dB
Output Noise: <3 µV
Gain: 35 dB (adjustable ±9 dB in 3 dB steps)
Maximum Analog Input: 2 Vrms
Maximum Digital Input: 0 dBFS
Maximum Output Voltage: 300 Vpp (1% THD)
Power Consumption: 680 W (IEC 60065, 1/8 power into 8Ω)
AC Voltage: 115 V or 230 V (±10%)
Dimensions (W × H × D): 16.5 × 32.5 × 19.7 in (42 × 82.6 × 50 cm)
Weight (per amplifier): 195 kg (430 lb)
Inputs & Connections
Balanced XLR analog input
Single-ended RCA analog input
Goldmund digital RCA input/output
RS-232 control
12V Trigger input
Dual speaker binding posts
Goldmund 4B speaker connector
Ground lift switch
Mechanical Grounding™ chassis with conical feet
Design Highlights
Four-channel internal amplifier architecture derived from the Telos 8800.
Completely redesigned power supply with custom capacitor banks.
Massive resin-coated transformers to minimize vibration.
Precision-machined aluminum chassis with integrated passive heatsinks.
Near-zero vibration, extremely low distortion, and exceptional speaker control through Goldmund's Mechanical Grounding™ and Telos® technologies.
